Description
| Specification | Value |
|---|---|
| Factory Lead Time | 4 Weeks |
| Contact Plating | Gold, Nickel |
| Chassis | Cable, Through Hole |
| Number of Pins | 1 |
| Contact Materials | Gold, Nickel |
| Packaging | Bulk |
| Series | DIN 41612 |
| Lead Free Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN Code | EAR99 |
| Type | Signal |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| HTS Code | 8536.90.40.00 |
| MIL Compliance | NO |
| DIN Standard Compliance | YES |
| IEC Compliance | NO |
| Orientation | Straight |
| Rated Current | 2A |
| Approval Agency | IEC |
| Number of Connectors | 216 |
| Contact Gender | Female |
| Contact Resistance | 20mOhm |
| Wire Gauge | 20-28 AWG |
| Wire Gauge (Maximum) | 28 AWG |
| Wire Gauge (Minimum) | 20 AWG |
| Wire / Cable Specification | 20 AWG |
| Contact Termination | Crimp |
| Pin or Socket | Socket |
| Assembly Item Name | CONTACT |
| Test Voltage | 1kV |
| Height | 1.2mm |
| Width | 19.45mm |
| Device Thickness | 1.2mm |
| SVHC Compliance | No SVHC |
| RoHS Status | ROHS3 Compliant |
