Description
| Specification | Value |
|---|---|
| Factory Lead Time | 12 Weeks |
| Package / Housing | 2512 (6432 Metric) |
| Chassis | Surface Mount |
| Contact Plating | Tin |
| Terminal Shape | WRAPAROUND |
| Published | 2006 |
| Series | CRE2512 |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -55°C~170°C |
| Size/Dimensions | 0.254Lx0.132W 6.45mmx3.35mm |
| Tolerance | ±1% |
| JESD-609 Code | e3 |
| Lead Free Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Number of Terminations | 2 |
| Termination | Solder |
| Temperature Coefficient | ±50ppm/°C |
| Resistance | 3mOhm |
| Construction | Metal Element |
| Additional Function | PRECISION |
| Rated Power | 3W |
| Packaging Method | TR, EMBOSSED, 7 INCH |
| Maximum Power Dissipation | 3W |
| Depth | 3.35mm |
| Structure | Rectangular Package |
| Resistor Type | Fixed Resistor |
| Case Code (Metric) | 6432 |
| Rated Power Dissipation (P) | 3W |
| Case Code (Imperial) | 2512 |
| Feature | Automotive AEC-Q200, Current Sense, Moisture Resistant |
| Seating Height (Max) | 0.035 0.90mm |
| Height | 889μm |
| RoHS Status | ROHS3 Compliant |
| REACH SVHC Status | No SVHC |
| Rating Result | AEC-Q200 |
