Description
| Category | Details |
|---|---|
| Brand | AUO |
| LCD Model | G190ETT01.1 |
| Operating Temperature | -30 ~ 85°C |
| Storage Temperature | -30 ~ 85°C |
| Application Equipment | Industrial |
| Current Production Status | In Mass Production |
| Structural Features | Details |
|---|---|
| LCD Screen Size | 19.0 inches |
| Dot Resolution | 1280(RGB)×1024, SXGA |
| Pixel Arrangement | RGB Vertical Stripe |
| Aspect Ratio | 5:4 (W:H) |
| Dot Pitch | 0.098×0.294 mm |
| Pixel Pitch | 0.294×0.294 mm [86PPI] |
| Surface Treatment | – |
| Display Area | 376.32(W)×301.056(H) mm |
| Outline Dimension | – |
| Outline Thickness | – |
| Visible Area | – |
| Weight | – |
| Touch Screen | Projected Capacitive Touch Screen, Die – cut Adhesive |
| Optical Features | Details |
|---|---|
| Display Mode | TN, Normal White Display, Transmissive |
| LCD Screen Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
| Display Color | 16.7M (6 – bit + Hi – FRC) |
| Response Time | 7/3 (Typ.)(Tr/Td) (ms) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Light Source Type | WLED |
| Signal Interface Parameters | Details |
|---|---|
| Signal Interface | LVDS (2 ch, 8 – bit) |
| Voltage Input | 5.0V (Typ.) |
