Description
| Parameter | Specification |
|---|---|
| Rating | Automotive |
| Integrated isolated power | No |
| Isolation rating | Functional |
| Number of channels | 4 |
| Forward/reverse channels | 2 forward / 2 reverse |
| Default output | High, Low |
| Data rate (max) (Mbps) | 50 |
| Protocols | GPIO, PWM, SPI, UART |
| CMTI (min) (V/μs) | 150000 |
| Operating temperature range (°C) | -40 to 125 |
| Supply voltage (max) (V) | 5.5 |
| Supply voltage (min) (V) | 1.71 |
| Propagation delay time (typ) (μs) | 0.011 |
| Creepage (min) (mm) | 3.7 |
| Clearance (min) (mm) | 3.7 |
