Description
| Attribute | Reference Value |
|---|---|
| Chassis | Through Hole |
| Package/Case | DIP |
| Number of Pins | 12 |
| Number of Elements | 140 |
| Series | HDLx-1414 |
| Published | 2012 |
| Size/Dimensions | 0.70Lx0.79W x 0.24 H 17.66mmx20.12mmx6.10mm |
| JESD-609 Code | e2 |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN Code | EAR99 |
| Terminal Finish | Tin/Copper (Sn/Cu) |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Color | Red |
| HTS Code | 8531.20.00.40 |
| Voltage – Rated DC | 5V |
| Number of Functions | 4 |
| Depth | 17.66mm |
| Operating Supply Voltage | 5V |
| Configuration | 5 x 7 |
| Interface | 7-Bit ASCII |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 4.5V |
| Forward Voltage | 5V |
| Luminous Intensity | 13.3 mcd |
| Millicandela Rating | 1.20mcd ~ 13.30mcd |
| Wavelength – Peak | 645 nm |
| Display Type | Dot Matrix |
| Number of Characters | 4 |
| Dominant Wavelength | 637 nm |
| Height | 6.096mm |
| Viewing Area (Height) | 3.61mm |
| Radiation Hardening | None |
| RoHS Status | ROHS3 Compliant |
| Lead Free | Lead Free |
