| Chassis |
Surface Mount |
| Mounting Type |
Surface Mount |
| Package/Case |
DO-213AC, MINI-MELF, SOD-80 |
| Pin Count |
2 |
| Mass |
51.84mg |
| Operating Temperature |
-65°C ~ 175°C |
| Packaging |
Tape & Reel (TR) |
| Tolerance |
±3% |
| Lead Free Code |
yes |
| Part Status |
Obsolete |
| Moisture Sensitivity Level (MSL) |
1 (Unlimited) |
| Rated Power |
500mW |
| Voltage – Rated DC |
22V |
| Maximum Power Dissipation |
500mW |
| Base Part Number |
FLZ22 |
| Working Voltage |
20.6V |
| Impedance |
25.6Ohm |
| Element Configuration |
Single |
| Reverse Leakage Current @ Vr |
133nA @ 17V |
| Power Dissipation |
500mW |
| Voltage – Forward (Vf) @ If |
1.2V @ 200mA |
| Maximum Reverse Leakage Current |
133nA |
| Impedance – Max |
25.6Ohm |
| Test Current |
5mA |
| Forward Voltage |
1.2V |
| Zener Voltage |
20.66V |
| Peak Reverse Current |
133nA |
| Voltage Tolerance |
2% |
| Zener Current |
5mA |
| Radiation Hardening |
None |
| RoHS Status |
RoHS Compliant |
| Lead Free |
Lead Free |
